Гусеничный экскаватор LiuGong CLG922E

922E
Operating Weight
22,000-23,850 kg

Rated Power
112-124 kW

Bucket Capacity
0.45-1.2 m³

Unmatched performance driven by the Cummins Engine enhances torque output with more power and breakout force at lower engine speeds.

Options for auxiliary hydraulic piping include bidirectional variable high flow line, an additional line for rotating attachments and also a single acting line. The quick coupler further ensures you get the most out of your machine by easily switching between a wide range of attachments to suit any application.

Ergonomically designed cab for LiuGong E series excavator, with great visibility, expansive room, new multi-function LCD monitor, automatic air conditioner, large storage space, provide most comfortable working environment
Hydraulic request signals detect activity, decreasing and increasing engine speed as required. Power is supplied only as needed, achieving optimum fuel efficiency.

Outstanding stability and durability come from an X-type reinforced frame and the long track beam and crawler system

922E - Stage II
Operating weight 22000 kg
Std. Bucket capacity 1.0 m³
Travel speed(Low) 3.3 km/h
Arm breakout force 97 kN
Bucket breakout force 140 kN
Shipping length 9540 mm
Shipping height 3140 mm
Boom 5710 mm
Digging reach 9870 mm
Digging depth 6562 mm
Cutting height 9945 mm
Minimum front swing radius 3090 mm
Emission Stage II / Tier 2
System pressure 34.3 MPa
Engine power 112 kW (150 hp) @ 1950 rpm
Travel speed(High) 5.7 km/h
Maximum swing speed 12.5 rpm
Arm breakout force Power boost 105 kN
Bucket breakout force Power boost 152.5 kN
Shipping width 2990 mm
Track shoe width (std) 600 mm
Arm 2915 mm
Digging reach on ground 9685 mm
Vertical wall digging depth 5080 mm
Dumping height 7170 mm
Model Cummins 6BTAA5.9-C150-Ⅱ
System maximum flow 2×224 L/min (2x59 gal/min)
